TZ25 series engineering plastic drag conveyor chain

Chain Energy New Design Top Quality Industrial Drag Chain Energy Drag Chain

---

Cable Drag Chain - The hoses & electrical cables connected to machinery parts in motion may get damaged as direct tension is applied on them; instead the use of Drag Chain eliminates this problem as the tension is applied on Drag Chain thus keeping the Cables & hoses intact & facilitating smooth movement.

Salient features include less weight, low noise, non-conductive, easy handling, non-corrosive, easy of assembly due to snap fitting, maintenance free, available in custom lengths, separators to segregate cables/hoses, can be used for side by side in case number of cables is more, increases cable/hoses life, modular design simplifies cable/hose maintenance.

The Cable Drag Chain Is assemblies of single units that are snap fitted to form chain to specific length.

advantage:

high degree of protection against mechanical damage of different conductors,

high-speed movement of equipment and machinery,

the ability to use the whole length of the track as a work area.

Trucking current feeder is a necessary component of any industrial machinery, machine tool, crane, - cables, wires, hydraulic and pneumatic hoses, which are constantly exposed to mechanical and climatic influences.

Plastic and steel energy chains may be used in a temperature range from -40 ° C to + 130 ° C.

Model table :

Model	Inner H×W	Outer  HX W	Bending Radius	Pitch	Unsupported length	Style
TZ 25x38	25x38	35x54	55.75.100	45	1.8meters	Half-enclosed and bottom lids can be opened
TZ 25x50	25x50	35x66
TZ 25x57	25x57	35x73
TZ 25x75	25x75	35x91
TZ 25x103	25x103	35x119



Application :

Cable drag chains can be used in a variety of applications, wherever there are moving cables or hoses. there are so many applications include; machine tools, process and automation machinery, vehicle transporters, vehicle washing systems and cranes. Cable drag chains come in an extremely large variety of sizes.
